Error code Description
8x24h Error in FC/SFC parameter x, where x:
1: Error in DATAPTR
2: Error in DATALEN
8122h Error in parameter DATAPTR
(e.g. DB too short)
807Fh Internal error
809Ah interface not found e.g. interface is used by
PROFIBUS
809Bh interface not configured
ASCII
Value Description
9000h Buffer overflow (no data send)
9002h Data too short (0byte)
STX/ETX
Value Description
9000h Buffer overflow (no data send)
9001h Data too long (>1024byte)
9002h Data too short (0byte)
9004h Character not allowed
3964R
Value Description
2000h Send ready without error
80FFh NAK received - error in communication
80FEh Data transfer without acknowledgement of partner or
error at acknowledgement
9000h Buffer overflow (no data send)
9001h Data too long (>1024byte)
9002h Data too short (0byte)
USS
Error code Description
2000h Send ready without error
8080h Receive buffer overflow (no space for receipt)
8090h Acknowledgement delay time exceeded
Protocol specific
RETVAL values
VIPA System 300SDeployment PtP communication
Communication> FC/SFC 217 - SER_SND
