Currently the VIPA programming cables for transfer via MPI are not
supported. This is only possible with the programming cable from Sie-
mens.
1. Establish a connection to the CPU via MPI with an appropriate
programming cable. Information may be found in the corre-
sponding documentation of the programming cable.
2. Switch-ON the power supply of your CPU and start the Siemens
TIA Portal with your project.
3. Select in the Project tree your CPU and choose ‘Context menu
è Download to device è Hardware configuration
’ to transfer
the hardware configuration.
4. To transfer the PLC program choose ‘Context menu
è Download to device è Software’. Due to the system you
have to transfer hardware configuration and PLC program sepa-
rately.
For transfer via Ethernet the CPU has the following interface:
n X5: Ethernet PG/OP channel
So that you may the according Ethernet interface, you have to assign
IP address parameters by means of the "initialization".
Please consider to use the same IP address data in your project for
the CP 343-1.
1. For the transfer, connect, if not already done, the appropriate
Ethernet jack to your Ethernet.
2. Open your project with the Siemens TIA Portal.
3. Click in the Project tree at Online access and choose here by a
double-click your network card, which is connected to the
Ethernet PG/OP interface.
4. Select in the Project tree your CPU and click at [Go online].
5. Set the access path by selecting "PN/IE" as type of interface,
your network card and the according subnet. Then a net scan is
established and the corresponding station is listed.
6. Establish with [Connect] a connection.
7.
Click to ‘Online è Download to device
’.
ð
The according block is compiled and by a request trans-
ferred to the target device. Provided that no new hardware
configuration is transferred to the CPU, the entered Ethernet
connection is permanently stored in the project as transfer
channel.
Transfer via MPI
Transfer via Ethernet
Initialization
Transfer
