Command Description Diagnostics entry
SET_NETWORK IP parameters for Ethernet PG/OP channel may
be set by means of this command. The IP
parameters are to be given in the order IP
address, subnet mask and gateway in the
format x.x.x.x each separated by a comma.
Enter the IP address if there is no gateway
used.
0xE80E
CMD_END In the last line CMD_END is to be located. 0xE802
The structure of a command file is shown in the following. The corre-
sponding diagnostics entry is put in parenthesizes.
Example 1
CMD_START
Marks the start of the command sequence (0xE801)
LOAD_PROJECT proj.wld
Execute an overall reset and load "proj.wld" (0xE805)
WAIT1SECOND
Wait ca. 1s (0xE803)
WEBPAGE
Store web page as "webpage.htm" (0xE804)
DIAGBUFF
Store diagnostics buffer of the CPU as "diagbuff.txt"
(0xE80B)
CMD_END
Marks the end of the command sequence (0xE802)
... arbitrary text ...
Text after the command CMD_END is not evaluated.
Example 2
CMD_START
Marks the start of the command sequence (0xE801)
LOAD_PROJECT proj2.wld
Execute an overall reset and load "proj2.wld" (0xE805)
WAIT1SECOND
Wait ca. 1s (0xE803)
WAIT1SECOND
Wait ca. 1s (0xE803)
IP parameter (0xE80E)
SET_NETWORK 172.16.129.210,255.255.224.0,172.16.129.210
WAIT1SECOND
Wait ca. 1s (0xE803)
WAIT1SECOND
Wait ca. 1s (0xE803)
WEBPAGE
Store web page as "webpage.htm" (0xE804)
DIAGBUFF
Store diagnostics buffer of the CPU as "diagbuff.txt"
(0xE80B)
CMD_END
Marks the end of the command sequence (0xE802)
... arbitrary text ...
Text after the command CMD_END is not evaluated.
The parameters IP address, subnet mask and gateway
may be received from the system administrator.
Enter the IP address if there is no gateway used.
Examples
VIPA System 300SDeployment CPU 313-6CF13
MMC-Cmd - Auto commands
HB140 | CPU-SC | 313-6CF13 | GB | 15-50 78
