Event-ID Description
0xEA66 PROFINET IO controller
Error in communication stack
PK: Rackslot
OBNr: StackError.Service
DatId: StackError.DeviceRef
ZInfo1: StackError.Error.Code
ZInfo2: StackError.Error.Detail
ZInfo3: StackError.Error.AdditionalDetail
<< 8 + StackError.Error.AreaCode
0xEA67 Error - PROFINET IO controller - reading record set
PK: Error type
0: DATA_RECORD_ERROR_LOCAL
1: DATA_RECORD_ERROR_STACK
2: DATA_RECORD_ERROR_REMOTE
OBNr: PROFINET IO controller slot
DatId: Device-No.
ZInfo1: Record set number
ZInfo2: Record set handle
ZInfo3: Internal error code for service purposes
0xEA68 Error - PROFINET IO controller - writing record set
PK: Error type
0: DATA_RECORD_ERROR_LOCAL
1: DATA_RECORD_ERROR_STACK
2: DATA_RECORD_ERROR_REMOTE
OBNo: PROFINET IO controller slot
DatId: Device-No.
ZInfo1: Record set number
ZInfo2: Record set handle
ZInfo3: Internal error code for service purposes
0xEA69 Internal error - Please contact the VIPA Hotline!
0xEA6A PROFINET IO controller
Service error in communication stack
PK: Rackslot
OBNo: ServiceIdentifier
DatId: 0
ZInfo1: ServiceError.Code
ZInfo2: ServiceError.Detail
ZInfo3: StackError.Error.AdditionalDetail
VIPA System 300SDeployment CPU 313-6CF13
VIPA specific diagnostic entries
HB140 | CPU-SC | 313-6CF13 | GB | 15-50 86
