95x Series Operating Manual - May 17, 2022
Page 129 of 155
COMMANDS
Clears the STB, SRE, OPC, ESR and ERR registers.
Resets the front panel to the LOCAL state.
Responds with a <NR1> field value of the ERR register then clears the
ERR register
Responds with a <NR1> field value of the ESR register then clears the ESR
register
Responds with a <NR1> field value of the OPC register then clears the
OPC register
Responds with a <NR1> field value of the SRE register
Responds with a <NR1> field value of the STB register then certain bits of
the STB register are cleared
Commands to create, edit, recall, or save the Active Test Sequence
(Cannot be used while a test sequence is running)
Add a test step to the end of the active sequence. See –
ACez Configuration Fields
ACW Configuration Fields
DCez Configuration Fields
DCW Configuration Fields
DCIR Configuration Fields
GBez Configuration Fields
GB Configuration Fields
LowΩ Configuration Fields
ACCAP Configuration Fields
ACI Configuration Fields
DCI Configuration Fields
PULSE Configuration Fields
BRKDN Configuration Fields
PAUSE Configuration Fields
HOLD Configuration Fields
SWITCH (948i configuration) Configuration Fields
SWITCH (964i configuration) Configuration Fields
Clears the lead compensation data from the active test sequence
Names the active test sequence
Clears the active test sequence
Recalls a test sequence from the requested store # and makes it the
active test sequence
Saves the active test sequence into the requested store #
Overwrite a step in the active sequence (see also ADD,…)
Commands to Run the Active Test Sequence
(Can only be used while a test sequence is not running)
Makes the active test sequence ready to be run by the START button
Runs the active test sequence
Runs the active test sequence in Lead Compensation mode
Running Test Sequence Control Commands
(Can only be used while a test sequence is running)
Aborts a running test sequence.
