95x Series Operating Manual - May 17, 2022
Page 28 of 155
UNKNOWN MENU LOCK PASSWORD
If the 95x menus have been locked but the password is unknown, the user should contact Vitrek for assistance.
The 95x has an internal set of “one time use” passwords for this circumstance.
DISPLAYING BUILD INFORMATION
• Ensure that the display indicates that the 95x is in the base menu state, i.e., the display shows the date
and time. If necessary, press the STOP button to abort a menu and return to the base menu state.
• Press the CNFG key.
• The display now shows the main configuration menu, an example of which is –
TEST…
PRINTOUT…
SYSTEM…
INTERFACES…
DIGITAL I/O…
BUILD…
SET TO DEFAULTS…
LOCK PASSWORD:000000
RELOCK…
• Using the Left Arrow or Right Arrow keys as needed, change the selection point to the BUILD line.
• Press the ENTER key.
• The 95x now displays the build configuration menu, an example of which is –
SERIAL# 123456
FIRMWARE: v1.12
FP: v1.10
MEAS: v1.10
DRIVE: v1.10
BASE UNIT: 951i
DC OPTION: NONE
AC2 OPTION: NO
AC30 OPTION: NO
500VA OPTION: NO
PMT1 OPTION: YES
HSS OPTION: NO
MAX DC: 6.5KV
MAX AC: 6.0KV
INTERFACE: GUL-3
UPGRADE:000000000000
• The user may navigate this menu but may not make changes to it. The information available is as follows-
o SERIAL#. This shows the serial number of this 95x.
o FIRMWARE. This shows the main firmware revision number installed in this 95x. This can be
upgraded (along with the MEAS and DRIVE firmware) by the user via the RS232, Ethernet or GPIB
interface. Contact Vitrek or your local representative for details regarding this.
o FP. This shows the front panel firmware revision number.
o MEAS. This shows the Measurement DSP firmware revision number installed in this 95x.
o DRIVE. This shows the Output Drive DSP firmware revision number installed in this 95x.
o BASE UNIT. This shows the base model number of this 95x.
