Vitrek 952i - Programming Example

95x Series Operating Manual - May 17, 2022
Page 149 of 155
12
Valid or
Empty
Empty
Empty
Empty
Valid
Empty
Empty
Empty
Empty
Empty
13
Valid or
Empty
Empty
Empty
Empty
Valid
Empty
Empty
Empty
Empty
Empty
14
Valid or
Empty
Empty
Empty
Empty
Valid
Empty
Empty
Empty
Empty
Empty
15
Valid or
Empty
Empty
Empty
Empty
Valid
Empty
Empty
Empty
Empty
Empty
16
Valid or
Empty
Valid or
Empty
Empty
Empty
Valid or
Empty
Valid or
Empty
Valid or
Empty
Empty
Valid or
Empty
Empty
17
Valid or
Empty
Valid or
Empty
Empty
Empty
Valid or
Empty
Valid or
Empty
Valid or
Empty
Empty
Valid or
Empty
Empty
18
Valid or
Empty
Valid or
Empty
Empty
Empty
Valid or
Empty
Valid or
Empty
Valid or
Empty
Empty
Valid or
Empty
Empty
19
Valid or
Empty
Valid or
Empty
Empty
Empty
Valid or
Empty
Valid or
Empty
Valid or
Empty
Empty
Valid or
Empty
Empty
Field
#
ACez,
ACW
DCez,
DCW,
DCIR
GBez,
GB
LowΩ
ACCAP
ACI
DCI
BRKDN
PULSE
PAUSE,
HOLD,
SWITCH
PROGRAMMING EXAMPLE
If the user wishes to be able to send a command to the 95x to test that the interface is active and functioning, then
the following could be used –
Example 1
• Send *IDN?<CR><LF> (don’t type the <CR><LF> just ensure that your application sends a carriage return
and/or line feed)
• Read the response back from the 95x, it should be similar to VITREK,952i,000000,v1.45,v1.23,v1.23,v1.23
• Refer to
•
•
• *IDN? Response Fields for details regarding the response.
Example 2
• Ensure there are no connections to any terminals on the 95x, this example is not applicable to the 959i.
• Send NOSEQ; ADD,ACEZ,1000.0,60.0,1.5,5.0,0.0,0.005,ABORT;RUN<CR><LF>
• The 95x will perform an ACez test at 1000Vrms/60Hz with a 1.5sec ramp and 5sec dwell.
• After completion send STEPRSLT?,1<CR><LF>
• The 95x responds with the results for the step which should be similar to
3,+5.01700E+00,0,+1.00012E+03,+60.0000E+00,+82.3600E-09,,+2.22916E-09,+2.10947E-09,+2.18633E-
09,+2.17637E-09,,,,,,,,
• Refer to
