CONNECTIONS
Refers to the instructions received with the specific Switch Matrix unit(s) for details regarding connecting the
terminals of the 95x to those of the Switch Matrix Units.
RS232 INTERFACE
Using a RS232 cable supplied by Vitrek, connect the RS232 port on the 95x rear panel to the RS232 (Serial) port of
the Vitrek 948i or 964i. The user may supply their own cable, in which case it should be a 9-wire female-female
null modem cable capable of full handshake 115200baud operation.
VICL
Using a VICL cable supplied by Vitrek, connect the VICL – OUT port on the 95x to a Vitrek 964i VICL – IN port. If
using more than one 964i, then connect each additional Vitrek 964i VICL – IN port to the preceding 964i’s VICL –
OUT port. The 964i’s do not need to be wired together in any specific order when using the VICL interface.
CONTROLLING THE 95X BY THE RS232 INTERFACE
NOTE – the RS232 interface can only be used for a single purpose, it cannot be used for both controlling an
external Switch Matrix unit and controlling the 95x.
SPECIFICATIONS
Baud Rate 9600, 19200, 57600 or 115200
Handshake Bi-directional, hardware (RTS/CTS)
Data Bits 8
Parity None
Start/Stop Bits 1
Connector 9-pin Male Dsub
Interface Pinout Type DTE (same as PC computer)
Cable required 9-wire female-female null modem cable, fully wired
Cable Length <50ft (per standard)
CONFIGURATION
• Ensure that the display indicates that the 95x is in the base menu state, i.e., the display shows the date
and time. If necessary, press the STOP button to abort a menu and return to the base menu state.
• Press the CNFG key.
• The display now shows the main configuration menu, an example of which is –
TEST…
PRINTOUT…
SYSTEM…
INTERFACES…
DIGITAL I/O…
BUILD…
SET TO DEFAULTS…
LOCK PASSWORD:000000
RELOCK…
• Using the Left Arrow or Right Arrow keys as needed, change the selection point to the INTERFACES line.
To Next Page
