Vitrek 952i - Lowω Configuration Fields

95x Series Operating Manual - May 17, 2022
Page 140 of 155
RAMP - Discharge same as ramp
11
<STRING>
ABORT - Abort on failure
CONT - Continue on failure
Example –
ADD,GB,25.0,60.0,5.0,0.0,60.0,RMSO,0.0,0.1,FAST,ABORT
Configures the following (in order) –
A GB type test step
25A test current
60Hz test frequency
5V max open circuit voltage
0 second ramp time
60 second dwell time
Check RMS impedance
No minimum impedance
0.1Ω maximum impedance
Fast discharge
Abort test sequence if fails
LOWΩ CONFIGURATION FIELDS
Field #
Field Format
Value
1
<STRING>
LOWOHM
2
<BOOL>
1 or Y - Test using 2-wire mode
0 or N - Test using 4-wire mode
3
<NR3>
Test time (in seconds)
<EMPTY>
Step is to be user terminated
4
<NR3>
Check delay (in seconds)
5
<NR3>
Minimum Resistance Limit (in Ω)
6
<NR3>
Maximum Resistance Limit (in Ω)
7
<STRING>
ABORT - Abort on failure
CONT - Continue on failure
Example –
ADD,LOWOHM,0,5.0,0.0,1.25,1.75,ABORT
Configures the following (in order) –
A LowΩ type test step
Use 4-wire mode
5 second test time
0 second delay
1.25Ω minimum resistance
1.75Ω maximum resistance
Abort test sequence if fails
