o The presence of lead compensation data in a test sequence is indicated on the display during test
sequence selection by the presence of a c immediately after the test sequence number.
o Any saved lead compensation data for a test sequence is automatically discarded if the test
sequence is selected for editing by using the EDIT key.
SECTION 6 – TEST STEPS
The previous section described how to use test sequences. This section describes how to choose and configure
each step within a test sequence and the specifications and limitations for each step type.
The table below gives an overall summary of the various types of activities available for each step. After the table
are individual sections giving full details for each of these activities. The user only need be conversant with the
section for each specific activity which the user intends to perform. The levels shown for each model is those for
the standard build, option content may change the available levels and/or frequencies.
When the user is selecting testing against the requirements of a safety standard, the information given in this
section should only be used as a guideline; the user should consult a safety testing professional for information
regarding the specific standard and application. The voltage ranges shown above assume the most common
option content for each model; see the specifications for each type of test step for the actual ranges.
CHOOSING WITHIN THE VOLTAGE WITHSTAND AND LEAKAGE TESTING GROUP
When Voltage Withstand and Leakage Testing is required, the user must first decide whether to perform this using
an AC, DC or pulsed voltage, the frequency to use, the limits to use, and the actual test type(s) to perform.
