ACEZ CONFIGURATION FIELDS
Field #
Field Format
Value
1
<STRING>
ACEZ
2
<NR3>
Test Voltage (in Vrms)
3
<NR3>
Test Frequency (in Hz)
4
<NR3>
Ramp Time (in seconds)
5
<NR3>
Dwell time (in seconds)
<EMPTY>
Step is to be user terminated
6
<NR3>
Minimum Leakage Limit (in Arms)
7
<NR3>
Maximum Leakage Limit (in Arms)
8
<STRING>
ABORT - Abort on failure
CONT - Continue on failure
9
<EMPTY>
Option AC-30 is not used, may only be <MISSING> if field 10 is also <MISSING>
<MISSING>
<STRING>
INT : Option AC-30 is not used
EXT : Option AC-30 is to be used (valid if option AC-30 is fitted)
10
<EMPTY>
Load is not grounded
<MISSING>
<STRING>
GND : Load is grounded (valid if option HSS is fitted)
ISO : Load is not grounded
Example –
ADD,ACEZ,1000.0,60.0,1.5,60.0,0.0,0.005,ABORT
Configures the following (in order) –
An ACez type test step
1000V test voltage
60Hz test frequency
1.5 second ramp time
60 second dwell time
No minimum leakage current limit
5mArms maximum leakage current limit (i.e., 7.07mApk breakdown limit)
Abort test sequence if fails
HV Terminal used (AC-30 not used or not installed) since both fields 9 and 10 are missing
DUT is isolated since both fields 9 and 10 are missing
ACW CONFIGURATION FIELDS
Field #
Field Format
Value
1
<STRING>
ACW
2
<NR3>
Test Voltage (in Vrms)
3
<NR3>
Test Frequency (in Hz)
4
<NR3>
Breakdown Limit (in Apk)
5
<NR3>
Ramp Time (in seconds)
6
<NR3>
Dwell time (in seconds)
<EMPTY>
Step is to be user terminated
7
<STRING>
NONE - No 1
st
checked leakage
RMSA - 1
st
checked value is RMS leakage current
