ACCAP CONFIGURATION FIELDS
Field #
Field Format
Value
1
<STRING>
ACCAP
2
<NR3>
Test Voltage (in Vrms)
3
<NR3>
Test Frequency (in Hz)
4
<NR3>
Breakdown Limit (in Apk)
5
<NR3>
Ramp Time (in seconds)
6
<NR3>
Dwell time (in seconds)
<EMPTY>
Step is to be user terminated
7
<NR3>
Minimum Capacitance Limit (in F)
8
<NR3>
Maximum Capacitance Limit (in F)
9
<NR3>
Minimum DF Limit (no units)
10
<NR3>
Maximum DF Limit (no units)
11
<NR1>
Time period for arc detection (4, 10, 15, 20, 30 or 40)
<EMPTY>
Arc detection disabled
12
<NR1>
Arc detection limit (in mA)
<EMPTY>
Only valid if arc detection disabled in field 11
13
<STRING>
NONE - No discharge if next step compatible
FAST - Fast discharge
RAMP - Discharge same as ramp
14
<STRING>
ABORT - Abort on failure
CONT - Continue on failure
15
<EMPTY>
Option AC-30 is not used, may only be <MISSING> if field 16 is also <MISSING>
<MISSING>
<STRING>
INT : Option AC-30 is not used
EXT : Option AC-30 is to be used (only valid if option AC-30 is fitted)
16
<EMPTY>
Load is not grounded
<MISSING>
<STRING>
GND : Load is grounded (only valid if option HSS is fitted)
ISO : Load is not grounded
Example –
ADD,ACCAP,1000.0,60.0,0.01,1.5,60.0,0.9e-9,1.1e-9,0.0,1.0,,,FAST,ABORT
Configures the following (in order) –
An ACCAP type test step
1000V test voltage
60Hz test frequency
10mApk breakdown limit
1.5 second ramp time
60 second dwell time
0.9nF minimum capacitance
1.1nF maximum capacitance
No minimum dissipation factor
No maximum dissipation factor (1.0 disables the maximum)
No arc detection (so following field is also <EMPTY>)
Fast discharge
