Vitrek 952i - SWITCH (948 I Configuration) Configuration Fields; SWITCH (964 I Configuration) Configuration Fields

95x Series Operating Manual - May 17, 2022
Page 145 of 155
A HOLD type test step
60 second timeout
SWITCH (948I CONFIGURATION) CONFIGURATION FIELDS
Field #
Field Format
Value
1
<STRING>
SWITCH
2
<NR3>
Pre-switch delay (in seconds)
3
<NR3>
Post-switch delay (in seconds)
4-10
<NR1>
Switch bank data banks 6-0 resp.
Example –
ADD,SWITCH,0.0,0.25,0x00,0x00,0x00,0x00,0x00,0x00,0x00
Configures the following (in order) –
A SWITCH type test step
0 second pre-switch delay
0.25 second post-switch delay
Bank #6 set to hexadecimal 00
Bank #5 set to hexadecimal 00
Bank #4 set to hexadecimal 00
Bank #3 set to hexadecimal 00
Bank #2 set to hexadecimal 00
Bank #1 set to hexadecimal 00
Bank #0 set to hexadecimal 00
SWITCH (964I CONFIGURATION) CONFIGURATION FIELDS
Field #
Field Format
Value
1
<STRING>
SWITCH
2
<NR3>
Pre-switch delay (in seconds)
3
<NR3>
Post-switch delay (in seconds)
4-11
<NR1>
964 #1 Switch bank data banks 7-0 resp.
12-19
<NR1>
964 #2 Switch bank data banks 7-0 resp. (only if configured for >1x964)
20-27
<NR1>
964 #3 Switch bank data banks 7-0 resp. (only if configured for >2x964)
28-35
<NR1>
964 #4 Switch bank data banks 7-0 resp. (only if configured for 4x964)
Example –
ADD,SWITCH,0.0,0.25,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00
Configures the following (in order) –
A SWITCH type test step
0 second pre-switch delay
0.25 second post-switch delay
Bank #7 set to hexadecimal 00
Bank #6 set to hexadecimal 00
Bank #5 set to hexadecimal 00
