Vitrek 952i - PAUSE Configuration Fields; HOLD Configuration Fields

95x Series Operating Manual - May 17, 2022
Page 144 of 155
2
<NR3>
Test Current Level (in A)
3
<NR3>
Initial Ramp Rate (in V/sec)
4
<NR3>
Minimum Breakdown Voltage (in V)
5
<NR3>
Maximum Breakdown Voltage (in V)
6
<STRING>
ABORT - Abort on failure
CONT - Continue on failure
7
<EMPTY>
Load is not grounded
<MISSING>
<STRING>
GND : Load is grounded (only valid if option HSS or HSS-2 is fitted)
ISO : Load is not grounded
Example –
ADD,BRKDN,0.001,1000.0,500.0,600.0,ABORT
Configures the following (in order) –
A BRKDN type test step
1mA test current level
1000V/sec initial ramp rate
500V minimum breakdown voltage
600V minimum breakdown voltage
Abort test sequence if fails
Load is not grounded (field 7 is missing)
PAUSE CONFIGURATION FIELDS
Field #
Field Format
Value
1
<STRING>
PAUSE
2
<NR3>
Pause time (in seconds)
Example –
ADD,PAUSE,5.0
Configures the following (in order) –
A PAUSE type test step
5 second pause time
HOLD CONFIGURATION FIELDS
Field #
Field Format
Value
1
<STRING>
HOLD
2
<NR3>
Timeout (in seconds)
Example –
ADD,HOLD,60.0
Configures the following (in order) –
