STEPRSLT? RESPONSE FIELDS
Field #
Field Format
Value
1
<NR1>
0 – Not executed
1 – Terminated during Ramp
2 – Terminated during Dwell (during delay)
3 – Terminated during Dwell (after delay)
Others – Terminated
2
<NR3>
Elapsed time of last executed period (in seconds)
3
<NR1>
Status of this step, see
Test Step Status Flags
4
<NR3> or <EMPTY>
Final test level (in Volts or Amps)
5
<NR3> or <EMPTY>
Final test frequency (in Hz)
6
<NR3> or <EMPTY>
Highest breakdown current (in Amps, peak)
7
<NR3> or <EMPTY>
Highest voltage (in Volts)
8
<NR3> or <EMPTY>
Highest 1
st
check result
9
<NR3> or <EMPTY>
Lowest 1
st
check result
10
<NR3> or <EMPTY>
Average 1
st
check result
11
<NR3> or <EMPTY>
Last 1
st
check result
12
<NR3> or <EMPTY>
Highest 2
nd
check result
13
<NR3> or <EMPTY>
Lowest 2
nd
check result
14
<NR3> or <EMPTY>
Average 2
nd
check result
15
<NR3> or <EMPTY>
Last 2
nd
check result
16
<NR3> or <EMPTY>
Highest arc current (in Amps)
17
<NR3> or <EMPTY>
Lowest arc current (in Amps)
18
<NR3> or <EMPTY>
Average arc current (in Amps)
19
<NR3> or <EMPTY>
Last arc current (in Amps)
Not all of the above fields are valid for each step type; fields which are not used for a step type are empty. The
table below shows the valid fields for each step type. The Check Result fields are empty if no check was defined or
performed; otherwise, they have the same units as used for the check limits (i.e., Volts, Amps, Ohms, Farads etc.).
Field
#
ACez,
ACW
DCez,
DCW,
DCIR
GBez,
GB
LowΩ
ACCAP
ACI
DCI
BRKDN
PULSE
PAUSE,
HOLD,
SWITCH
1
Valid
Valid
Valid
Valid
Valid
Valid
Valid
Valid
Valid
Valid
2
Valid
Valid
Valid
Valid
Valid
Valid
Valid
Valid
Valid
Valid
3
Valid
Valid
Valid
Valid
Valid
Valid
Valid
Valid
Valid
Valid
4
Valid (in
V)
Valid (in
V)
Valid
(in A)
Empty
Valid (in
V)
Valid (in
V)
Valid (in
V)
Empty
Empty
Empty
5
Valid
Empty
Valid
Empty
Valid
Valid
Empty
Empty
Empty
Empty
6
Valid
Valid
Empty
Empty
Valid
Empty
Empty
Valid
Valid
Empty
7
Empty
Empty
Empty
Empty
Empty
Empty
Empty
Valid
Valid
Empty
8
Valid or
Empty
Valid
Valid
Valid
Valid
Valid
Valid
Empty
Empty
Empty
9
Valid or
Empty
Valid
Valid
Valid
Valid
Valid
Valid
Empty
Empty
Empty
10
Valid or
Empty
Valid
Valid
Valid
Valid
Valid
Valid
Empty
Empty
Empty
11
Valid or
Empty
Valid
Valid
Valid
Valid
Valid
Valid
Empty
Empty
Empty
