– 5 –
ITEM
LABEL
DESCRIPTION
SEE PAGE:
16.
AUDIO IN
Connect an AUDIO cable from the input device.
17.
IR
Receive IR signal from remote control.
18.
12V OUT
When connected to the screen through a commercially available
cable, the screen deploys automatically on start up of the projector.
The screen retracts when the projector is powered off (see notes
below).
19.
AUDIO OUT
Connect an AUDIO cable for audio loop through.
20.
AUDIO OUT L/R
Connect an AUDIO cable for audio loop through.
21.
AUDIO IN L/R
Connect the audio cables from an audio device for VIDEO or S-
VIDEO audio input.
22.
VIDEO
Connect the composite cable from a video device.
23.
MICROPHONE
Connect the microphone input device.
24.
SERVICE
For service personnel only.
25.
WIRE REMOTE
Connect the wire remote from remote control to the projector for wire
remote control.
Connect "WIRE REMOTE OUT" to another projector (same model)
"WIRE REMOTE IN" for serial control.
26.
AC IN
Connect the POWER cable.
Note:
 To use this feature, you must plug in the connector before turn on/off the projector.
 Screen controllers are supplied and supported by screen manufacturers.
 Do not use this jack for anything other than intended use.
Warning:
As a safety precaution, disconnect all power to the projector and connecting devices before making
connections.
