5. To invert the color in the
display image, press Ink
Saver and turn on or off the
Ink Saver.
Ink Saver
Off
6. Press the Hardcopy key.
The file or folder will be
saved to the root directory
of the SD card.
Hardcop
y
DSO-4000 User Manual
78
Save
This section describes how to save data using the Save/Recall menu.
File type/source/destination
Item Source Destination
Panel setup
(xxxx.set)
• Panel settings
• Internal memory: S1 ~
S15
• External memory: SD
card
Waveform data
(xxxx.csv)
• Channel 1, 2
• Math operation
result
• Reference
waveform A, B
• Internal memory: W1 ~
W15
• Reference waveform A, B
• External memory: SD
card
Display image
(xxxx.bmp)
• Display image
• External memory: SD
card
Save All
• Display image
(xxxx.bmp)
• Waveform data
(xxxx.csv)
• Panel settings
(xxxx.set)
• External memory: SD
card
SD Card
restriction
The DSO-4000 series accept the following SD card.
Size: 2GB or less
Format: FAT or FAT32
