83
Display image
(Axxxx.bmp)
The current display image in
the bitmap format.
Waveform data
(Axxxx.csv)
Two types of waveform data
are saved: the currently active
channel data and the last
internally saved data (one of
W1 ~ W15).
4. Press Ink Saver repeatedly to
invert the background color
(on) or not (off) for the
display image.
Ink Saver
Off
5. Press Destination.
SD card
External card, no practical
limitation for the amount of file.
When saved, the folder will be
placed in the root directory.
6. Press Save to confirm
saving. When completed, a
message appears at the
bottom of the display.
Save
Note
The file will not be saved if the
power is turned off or SD card is
disconnected before completion.
7. Together with the current setup/waveform/
image, the last saved waveform file (one from
W1 ~ W15) and setup file (one from S1 ~ S15)
are also included in the folder.
File utilities
To edit SD card contents
(create/ delete/ rename files
and folders), press File Utilities.
For details, see page74.
DSO-4000 User Manual
84
Recall
File type/source/destination
Item Source Destination
Default panel
setup
• Factory installed
setting
• Current front panel
Reference
waveform
• Internal memory: A, B • Current front panel
Panel setup
(DSxxxx.set)
• Internal memory: S1 ~
S15
• External memory: SD
card
• Current front panel
Waveform data
(DSxxxx.csv)
• Internal memory: W1 ~
W15
• External memory: SD
card
• Reference waveform
A, B
SD Card
restriction
The DSO-4000 series accept the following SD card.
Size: 2GB or less
Format: FAT or FAT32
Recalling the default panel settings
Procedure
1. Press the Save/Recall key.
Save/Recal
l
2. Press Default Setup. The
factory installed setting will
be recalled.
Default
Setup
Setting contents
The following is the default panel setting contents.
Acquisition
Mode: Normal
Channel
Coupling: DC Invert: Off
BW limit: Off
(DSO-4102, DSO-4062)
Probe attenuation: x1
