9
Storage
environment
• Location: Indoor
• Relative Humidity: < 85%
• Temperature: 0°C to 50°C
Power cord for the United Kingdom
When using the oscilloscope in the United Kingdom, make sure the
power cord meets the following safety instructions.
NOTE: This lead/appliance must only be wired by competent persons
WARNING: THIS APPLIANCE MUST BE EARTHED
IMPORTANT: The wires in this lead are coloured in accordance with the
following code:
Green/ Yellow: Earth
Blue: Neutral
Brown: Live (Phase)
As the colours of the wires in main leads may not correspond with the
colours marking identified in your plug/appliance, proceed as follows:
The wire which is coloured Green & Yellow must be connected to the Earth
terminal marked with the letter E or by the earth symbol
or coloured Green
or Green & Yellow.
The wire which is coloured Blue must be connected to the terminal which is
marked with the letter N or coloured Blue or Black.
The wire which is coloured Brown must be connected to the terminal marked
with the letter L or P or coloured Brown or Red.
If in doubt, consult the instructions provided with the equipment or contact
the supplier.
This cable/appliance should be protected by a suitably rated and approved
HBC mains fuse: refer to the rating information on the equipment and/or
user instructions for details. As a guide, cable of 0.75mm2 should be
protected by a 3A or 5A fuse. Larger conductors would normally require 13A
types, depending on the connection method used.
Any moulded mains connector that requires removal /replacement must be
destroyed by removal of any fuse & fuse carrier and disposed of immediately,
as a plug with bared wires is hazardous if a engaged in live socket. Any re-
wiring must be carried out in accordance with the information detailed on
this label.
DSO-4000 User Manual
10
GETTING STARTED
The Getting started chapter introduces the
oscilloscope’s main features, appearance, and set
up procedure.
Main Features
Model name Frequency bandwidth Input channels
DSO-4022 DC – 25MHz (–3dB) 2
DSO-4042 DC – 40MHz (–3dB) 2
DSO-4062 DC – 60MHz (–3dB) 2
DSO-4102 DC – 100MHz (–3dB) 2
Performance
• 250MSa/S real-time sampling rate
• 25GS/s equivalent-time sampling rate
• Up to 10ns peak detection
Feature
• 5.6 inch color TFT display
• Saving and recalling setups and waveforms
• 19 automatic measurements
• Multi-language menu
• Math operation: Add, Subtract, FFT
• Edge, video, pulse width trigger
• Compact size: (W) 310 x (D) 140 x (H) 142 mm
Interface
• SD card connector for saving and recalling data
• Calibration output
• External trigger input
