Grease quality

Lithium based grease with EP additives and of

consistency NLGI no. 2. Check the following fluid

levels in connection with lubrication service:

• batteries

• cooling system

• washer reservoirs

4x2, 6x2, 8x2 vehicles with hydraulically

controlled bogies

J1007420

A=Lubrication points

B=Fluid level check

608

Maintenance
