C=Oil change and filter change
1 Brake cam (one on each wheel, not included on
disc brakes)
2 Steering arm, 8x2 and 8x4
3 Spare wheel holder
4 Spring anchorage (2 pcs for 6x2 and 8x2)
5 Cylinder, bogie lift (2 pcs)
6 Axle, bogie lift (4 pcs)
7 Roller, balance arms (2 pcs)
8 Roller, bogie lift
9 Balance arms (6 pcs).
First, grease the grease nipple in the centre until
grease is forced out by the sealing ring
or the overflow hole. Then grease both the other
grease nipples until grease
is forced out.
10 Cradle (2 pcs, not included on air suspension).
Grease until grease is forced out.
11 Clutch fluid reservoir
12 Pump for cab tilt
13 Motor
14 Steering servo reservoir
15 Steering servo reservoir for dual servo systems
(certain versions of 8x2 and 8x4)
16 Manual gearbox
17 Automatic gearbox
18 Hydraulic oil tank (some variants)
19 Rear axle (2 pcs for 6x4 and 8x4)
20 Bogie lift (must be lowered when changing oil or
checking oil level)
The parking brake must be released when lubricating
so that grease can be forced in properly
to the brake cams. (Applies to vehicles with drum
brakes.) Chock a wheel with wooden blocks
or similar, so that the vehicle cannot start moving
during service work.
Maintenance
609
