SHB 28Z3 EN – Edition 2.0 * 28z3s612.fm 6-17
Electrical system
No. Up to To Colour
93 S5 oil filter X10/6 org-wht 1
94 A1.1/6 right-hand side loudspeaker X12/6 grn-blk 1
95 A1.1/5 right-hand side loudspeaker X12/7 grn 1
96 A1.1/4 left-hand side loudspeaker X12/12 gry 1
97 A1.1/3 left-hand side loudspeaker X12/13 gry-blk 1
100 Y1/3 earth GND blk 1
101 Y13 earth GND blk 1
102 Y3 earth GND blk 1
103 M9 earth GND blk 1
104 M5 earth GND blk 1
105 M5 earth K7/5 blk 1
106 K6 earth GND blk 1
107 K6 earth K8 blk 1
108 V1 earth K8 blk 1
109 X14/2 earth GND blk 1
110 X14/2 earth S5 blk 1
111 M4/2 earth GND blk 1
112 M4/2 earth B1/2 blk 1
113 X19 earth GND blk 1
114 X19 earth E11/2 blk 1
115 Y25/2 earth GND blk 1
116 S41/2 earth GND blk 1
117 E15 earth GND blk 1
118 X12/5 earth GND blk 2.5
119 X4/3 earth GND blk 1
120 X4/3 earth S42/9 blk 1
121 S40/9 earth S42/9 blk 1
122 S40/9 earth B19/2 blk 1
123 S15/9 earth B19/2 blk 1
124 S15/9 earth S21/9 blk 1
125 S55/2 earth S21/9 blk 1
126 S55/2 earth X10/5 blk 1
127 S20/9 earth GND blk 1
128 S20/9 earth S16/9 blk 1
129 S17/9 earth S16/9 blk 1
130 S17/9 earth S18/9 blk 1
131 A1/8 earth S18/9 blk 1
132 X12/10 earth GND blk 1.5
