118
OPERATING MANUAL
VERSION 05/2017 ORDER NUMBER DOC 2357061
13.5.1 REMOTE CONTROL ASSEMBLING
13.5.1.1 SOFTWARE SETTINGS
Log in as the administrator (Level 3 password).
Set the remote control option to ON.
Menu
Level 3
Parameter Setting
Remote control ON
13.5.1.2 ASSEMBLY ON CONTROL CABINET
Observe safety instructions in Chapter 13.5.2.
1. Before connecting the remote control or an extension cable, de-energize the device.
In other words, switch o the main switch and unplug the power plug.
2. Plug the plug on the underside of the control cabinet into the socket intended for it.
3. Ground the remote control's ground wire.
13.5.1.3 TESTING AND COMMISSIONING
Make sure that the commands and signals described in Chapter 13.5.3 are being
transmitted. To do this, activate and check the various functions on the control cabinet
and remote control in turn.
Function Impact on control cabinet Impact on remote control
Start Green push button lights up START LED lights up
Stop Red push button lights up STOP LED lights up
Flushing Blue push button lights up FLUSH LED lights up
Recipe change The recipe is changed on the display.
The recipe displayed matches that
of the remote control.
The display in the center of the
remote control changes the
number (counting upward).
The impacts are always the same regardless of whether the function is activated on the
remote control or control cabinet. Activate all functions on remote control and control
cabinet at least once.
Carry out commissioning and parameter settings according to the operating manual and
the 2K COMFORT software manual.
