23
OPERATING MANUAL
VERSION 05/2017 ORDER NUMBER DOC 2357061
5 DESCRIPTION
5.1 COMPONENTS
The 2K system is clearly structured. It can be controlled using easy-to-understand and
easily accessible operating elements.
Control cabinet
All electrical components are installed in the control cabinet. The system can be controlled
via the four push-buttons and the operating panel (touch screen). Information can be
displayed or be entered via the operating panel.
Fluid section
The uid section contains all parts which come into contact with the 2K products.
5.2 MODE OF OPERATION
The system is suitable for measuring (dosing) and for mixing two or multi-component
products.
An electronic controller monitors and regulates the predetermined ratio of
components. The controller regularly adds in the necessary quantity of hardener -in
short intervals (and by way of pulses)- via a valve to the ow of base lacquer.
The ow of the base lacquer and hardener is measured with ow meters. In the case
of piston pumps, stroke sensors can be used if desired.
The components and ushing agents are made available by supplying pumps or
pressure tanks (not supplied with the system).
Paint selection
The mixing ratio, pot life etc. are stored in the recipe. By means of a simple recipe change,
the paint can be changed.
Further characteristics and areas of application
For low to medium pressure (32.5 MPa; 325 bar; 4714 psi).
2K COMFORT XL for high-pressure (53 MPa; 530 bar; 7687 psi).
Modular structure - can be combined as required by the customer.
Electronic dosing precision guarantees consistent quality.
Processing even water-based 2K products, since all parts carrying the product are
suitable to do so - made, for example, of stainless steel.
The uid section of the Ex version is suitable for use in potentially explosive areas
(zone 1 and zone 2).
Many functions are displayed in a language-independent way with icons which are
easy to understand. Texts are displayed in the selected language.
The overview of consumption of each component and ushing agent, VOC documentation.
Storage of the last 700 error messages indicating date and time.
Security by permanently checking the system parameters, operator information, in
case of the slightest trouble, and if necessary, automatic interruption of the production.
Protection of the parameters by security code. Settings can be saved on a USB stick.
