56
OPERATING MANUAL
VERSION 05/2017 ORDER NUMBER DOC 2357061
7.5.3 PASSWORDS
Some functions and input options are protected by passwords. The following password
levels exist:
Password level Responsibility Functions
0 Painter Spraying mode
1 Painter with control jobs
Plus enter ushing and paint recipes,
diagnosis, calibration
2 Foreman Plus system settings
3 Service customer Plus basic system settings
4
WAGNER Service
Department
−
The passwords, which are set by WAGNER at the time of the equipment delivery, are not
contained in the manual for safety reasons. The valid passwords are communicated to the
customer separately.
Password input
1. [Menu] button
2. If [Log Out] button appears: [Log Out] ( The button switches to [Log In].)
3. [Log In]
4. Touch password input eld.
A numerical keyboard appears.
5. Enter the password.
6. [ENT]
The password level is displayed briey, for example: "Level 1".
The menu buttons for the corresponding password level then appear.
7.6 HOME PAGE
NOTICE
Wrong mixing ratio!
Poor quality of paint application.
Before changing the lacquer, check the mixing ratio on the display and modify it if
necessary, if individual components have dierent mixing ratios.
7.6.1 CHANGING THE PAINT RECIPE
R
Press RECIPE CHANGE push button
Switches to next paint recipe.
Or:
1. Touch paint recipe eld (see above).
2. Select desired paint recipe from the list.
