OPERATING MANUAL
VERSION 05/2017 ORDER NUMBER DOC 2357061
7.4 MECHANICAL PUSHBUTTONS
The system's basic functions are controlled by four mechanical push-buttons:
START STOP Flushing RECIPE CHANGE
R
Starts spraying mode.
Flashes green during
lling.
Lights up green as soon
as the system is ready for
spraying. The AirCoat air
is activated (option).
Ends the spraying
or ushing process.
(Depending on setting,
it may not be possible to
end the ushing process
early.)
Alarm
Lights up red.
Warning Flashes red.
Starts end ushing of
the last paint recipe
used. (With external
mixer if necessary mixer
ushing.)
Lights up blue during
ushing process.
Switches to next paint
recipe.
STOP + recipe change
jumps 10 steps.
Display of lling
progress:
Display of ushing
progress:
Gun symbol ashes Open gun.
7.5 OPERATING PANEL BASICS
highlighted (yellow)
Some buttons are highlighted by a yellow
background color. The highlighted buttons indicate
our current location.
All elds with frames can be touched. For example, to trigger an
action, select a dierent recipe, or enter a number.
Recurring operating elements
Scroll up screen Conrm selection Saves the data
Scroll down screen Cancel selection
Dierences in screen displays
The controller's functions dier depending on system, accessories installed, and user
settings. The screens shown in the following chapters may therefore contain additional
input options, or some of the buttons and elds shown may not be present in your version.
The screen will only ever show what is actually installed.
