73
OPERATING MANUAL
VERSION 05/2017 ORDER NUMBER DOC 2357061
7.14 OPERATING PANEL FOR 2CIRCUIT SYSTEM
The operating panel controls either the uid
circuit 1 or the uid circuit 2.
Current uid circuit:
= Fluid circuit 1
= Fluid circuit 2
1/2 = aects both uid circuits
Touch = Go to the other uid circuit
Background color of page:
Turquoise = Fluid circuit 1
Orange = Fluid circuit 2
White = both uid circuits
On the home page are always both pot lives,
each with the appropriate background
color:
Pot life Circuit 1
Pot life Circuit 2
Example: Home page for circuit 1
min
Pot life
Menu Act.
Gun
Batch
AB : C
A : B
PC
min
1
7.14.1 CHANGE FLUID CIRCUIT
Touch the current upper right uid circuit, for example:
Thereafter, the controller switches to the other uid circuit. The page remains the same.
Example: the controller changes from the menu page for circuit 1 to the menu page for
circuit 2.
Change not possible
This error message appears if the current page is not available in the other uid circuit:
Change to circuit X is not possible.
Go to another page (for example to the home page). Then change the uid circuit.
On some pages, the current uid circuit is framed in gray. Then a change to another circuit
is also not possible. Remedy is the same:
Go to another page. Then change the uid circuit.
