PEM-X1
OPERATING MANUAL
VERSION 09/2012 ORDER NUMBER DOC 2326020
Dimensions:
Length/width/height see chapter 5.3.1
Weight 490 g; 1.08 lbs
Electrical:
Input voltage maximum of 22 Vpp
Input current maximum of 0.9 A
Frequency 19 - 30 kHz
Output voltage maximum of 100 kV DC
max. Corona current 120 μA
Polarity negative
Construction type in accordance with EN 50050-2
Protection class IP 64
Pneumatic:
Input air pressure (atomizer air volume) maximum of 3 bar; 0.3 MPa, 43.51 psi
Powder output quantity maximum of 450 g/min; 0.99 lbs/min.
Ambient conditions:
Operating temperature range 5 - 45 °C; 41 - 113 °F
Relative humidity < 75 %
5.3 TECHNICAL DATA
Ambient conditions:
If low-melting powders are used, the ambient temperature may have to be below 30 °C;
86 °F.
Volume measures:
for volumes speci ed in Nm³ (standard cubic meters). One standard cubic meter is one
cubic meter of gas at 0 °C and 1.013 bar.
Outgoing air containing oil!
Risk of poisoning if inhaled.
Insu cient paint application quality.
Make compressed air free from oil and water available (quality
standard 3.5.2 according to ISO 8573.1) 3.5.2 = 5 μm / +7 °C;
44.6 °F / 0.1 mg/m³.
