WAGNER PEM-X1 Original Operating Manual

57
PEM-X1
P_01697
OPERATING MANUAL
VERSION 09/2012 ORDER NUMBER DOC 2326020
12.7 NOZZLE EXTENSION X1 VL 150/300
12.8 POWDER HOSE
Order No. Designation
351794 Powder hose 9 mm
2310699 Powder hose
10 mm
2307502 Powder hose 11 mm
2310700 Powder hose
12 mm
Pos K Stk Order No. Designation
1 2323366 X1 VL 150 nozzle extension (150 mm; 5.91 inches)
1 2323356 X1 VL 300 nozzle extension (300 mm; 11.81 inches)
1 2324148 Round spray nozzle X1 VL ET
available as accessory, not included in the purchased parts package
