41
PEM-X1
2.
P_01678
3.
4.
5.
6.
OPERATING MANUAL
VERSION 09/2012 ORDER NUMBER DOC 2326020
8.6 FITTING THE ROUND SPRAY NOZZLE
Procedure:
Note:
1. Before inserting the electrode holder, the spring
contact of the gun body and contact surface of
the electrode holder should be checked.
The spring contact must be clean and smooth-
running, the gun body must also be clean and
free of powder deposits.
2. Attach de ector cone sleeve onto electrode
holder.
3. Insert electrode holder into gun housing.
4. Slide cap nut onto gun housing.
5. Screw cap nut onto gun housing (hand-tight).
6. Slide de ector cone over de ector cone sleeve.
To Next Page
