4
PEM-X1
OPERATING MANUAL
VERSION 09/2012 ORDER NUMBER DOC 2326020
7 OPERATION 27
7.1 Quali cation of the Operating Sta 27
7.2 Safety Instructions 27
7.3 Optimizing the Powder Cloud for Coating 28
7.3.1 Recommended Settings for Total Air Volume 28
7.4 Switching o the Spray Gun 29
7.5 Adjustment of Powder Quantity 30
7.6 "Double Click" Recipe (High Dynamic Remote) 31
7.7 Reproducible Setting of the Nozzle Position 32
8 CLEANING AND MAINTENANCE 33
8.1 Cleaning 33
8.1.1 Cleaning Sta 33
8.1.2 Safety Instructions 33
8.1.3 Cleaning Procedures 34
8.2 Maintenance 35
8.2.1 Maintenance Sta 35
8.2.2 Safety Instructions 35
8.2.3 Maintenance Procedures 36
8.2.4 Replacing the Spray Gun 37
8.3 Removing the Flat Spray Nozzle 38
8.4 Fitting the Flat Spray Nozzle 39
8.5 Removing the Round Spray Nozzle 40
8.6 Fitting the Round Spray Nozzle 41
8.7 Replacing the Protective Wedge 42
8.8 Changing from Flat Spray Nozzle to Round Spray Nozzle 44
8.9 Mounting the Corona-Star 46
8.10 Replacing the Suspension Hook 47
9 INSPECTIONS IN ACCORDANCE WITH DIN EN 50177: 2010 48
9.1 Overview of Inspections 49
10 DISASSEMBLY AND DISPOSAL 52
10.1 Disassembly 52
10.2 Disposal 52
11 TROUBLESHOOTING AND RECTIFICATION 53
12 ACCESSORIES 55
12.1 Flat Spray Nozzle 55
12.2 De ector Cone 55
12.3 Electrode Holder 55
12.4 Hose Take-Up 56
12.5 Retro t Set Corona-Star 56
12.6 Wedge Tool 56
12.7 Nozzle Extension X1 VL 150/300 57
12.8 Powder Hose 57
12.9 Wall Mount 58
12.10 Powder Measuring Adapter 59
