WAGO I/O SYSTEM 750 XTR Commissioning 143
750-8202/040-000 PFC200 2ETH RS XTR
Manual
Version 1.2.0, valid from FW Version 03.01.07(13)
7.8.1.12.3 “Add New User Filter” Group
You can enter 10 filters.
You only have to enter values in the fields that are to be set for the filter. At least
one value must be entered, all other fields can remain empty.
Table 73: WBM “Configuration of User Filter” Page – “Add New User Filter” Group
Policy
Select here whether the network devices is to be
allowed or excluded by the filter.
The network device is permitted.
The network device is excluded.
Source IP address
Enter here the source IP address for the new filter
entry.
Source netmask
Enter here the source network mask for the new
filter entry.
Source port
Enter here the source port address for the new filter
entry.
Destination IP address
Enter here the destination IP address for the new
filter entry.
Destination subnet mask
Enter here the destination network mask for the new
filter entry.
Destination port
Enter the destination port number for the new filter
entry.
Protocol
Enter here the permitted protocols for the new filter.
The TCP service is permitted.
The UDP service is permitted.
Input interface
Enter here the permitted interfaces for the new filter.
The X1 interface is permitted.
The X2 interface is permitted.
The VPN interface is permitted.
To accept the new filter click [Add]. The change is effective immediately.
