WAGO PFC200 2ETH RS XTR User Manual

334 Diagnostics WAGO I/O SYSTEM 750 XTR
750-8202/040-000 PFC200 2ETH RS XTR
Manual
Version 1.2.0, valid from FW Version 03.01.07(13)
Table 231: Diagnostics via SYS LED
Status
Explanation
Remedy
Green
Ready to operate -
System start
completed without
errors
---
Orange
Device is in
startup/boot process
and the RST button is
not pressed.
---
Load above threshold
value 1
The system is at full
capacity; real-time
response can no
longer be guaranteed.
Try to reduce the load on the system:
- Change the CODESYS program.
-
End any fieldbus communication that
is not essential, or reconfigure the
fieldbuses.
- Remove any non-critical tasks from
the RT area.
- Select a longer cycle time for IEC
tasks.
Orange flashing
“Fix IP Address”
mode,
temporary setting
until the next reboot
Connect to the device via the standard
address (192.168.1.17) or restart the
device to restore the original value set.
Red
Load above threshold
value 2
The system is
overloaded; real-time
response can no
longer be guaranteed.
Try to reduce the load on the system:
- Change the CODESYS program.
-
End any fieldbus communication that
is not essential, or reconfigure the
fieldbuses.
- Remove any non-critical tasks from
the RT area.
- Select a longer cycle time for IEC
tasks.
Green/red
flashing
Firmware update
mode
---

WAGO PFC200 2ETH RS XTR Specifications

General

Processor	ARM Cortex-A8
Clock Speed	600 MHz
RAM	256 MB
Ethernet Ports	2
Protection Class	IP20
Power Supply	24 V DC
Serial Ports	1 (RS-232/RS-485)
Operating Temperature	-40°C to +70°C
Programming Languages	IEC 61131-3
Certifications	UL
