WAGO PFC200 2ETH RS XTR User Manual

260 Run-time System CODESYS 2.3 WAGO I/O SYSTEM 750 XTR
750-8202/040-000 PFC200 2ETH RS XTR
Manual
Version 1.2.0, valid from FW Version 03.01.07(13)
The following events can be activated:
Table 202: Events
Name
Description
start
The event is called directly after the user program starts.
stop
The event is called directly after the user program stops.
before_reset
The event is called directly before the user program is
reset.
after_reset
The event is called directly after the user program is
reset.
shutdown
The event is called directly before the user program is
shutdown.
excpt_watchdog
The event is called if a task watchdog is recognized.
excpt_access_violation
The event is called if a memory access error to an
invalid memory area is recognized. (incorrect pointer,
invalid array index, invalid data descriptor)
excpt_dividebyzero
The event is called if a division by zero is recognized.
after_reading_inputs
The event is triggered after reading all of the inputs
independent of the user program.
before_writing_outputs
The event is triggered before writing all of the outputs
independent of the user program.
debug_loop
This event is triggered at every task call, if a breakpoint
was reached in this task and the processing of this task
is therefore blocked.
online_change
This event is called up after initialization of the program
on an online change.
before_download
This event is always called up before a download from
the IDE to the device takes place.
Application stops on a non-defined event handler!
If “excpt” events occur in the system and an event handler has not been defined,
the application goes into the “Stop” status.

WAGO PFC200 2ETH RS XTR Specifications

General

Processor	ARM Cortex-A8
Clock Speed	600 MHz
RAM	256 MB
Ethernet Ports	2
Protection Class	IP20
Power Supply	24 V DC
Serial Ports	1 (RS-232/RS-485)
Operating Temperature	-40°C to +70°C
Programming Languages	IEC 61131-3
Certifications	UL
