WAGO PFC200 2ETH RS XTR User Manual

302 Modbus – CODESYS 2 WAGO I/O SYSTEM 750 XTR
750-8202/040-000 PFC200 2ETH RS XTR
Manual
Version 1.2.0, valid from FW Version 03.01.07(13)
Table 217: Modbus Mapping for Read Register Services FC3, FC4, FC23
Modbus Address
(hexadecimal values
in parentheses)
IEC 61131
Address
Description
12288 … 65535
(0x3000 … 0xFFFF)
%MW0 …
%MW53247
Maximum addressable flag area:
53248 register/word flags (104 kB);
the actual addressable flag area
depends on the current memory
arrangement in CODESYS.

WAGO PFC200 2ETH RS XTR Specifications

General

Processor	ARM Cortex-A8
Clock Speed	600 MHz
RAM	256 MB
Ethernet Ports	2
Protection Class	IP20
Power Supply	24 V DC
Serial Ports	1 (RS-232/RS-485)
Operating Temperature	-40°C to +70°C
Programming Languages	IEC 61131-3
Certifications	UL
