WAGO PFC200 2ETH RS XTR User Manual

WAGO I/O SYSTEM 750 XTR Run-time System CODESYS 2.3 251
750-8202/040-000 PFC200 2ETH RS XTR
Manual
Version 1.2.0, valid from FW Version 03.01.07(13)
8.2.5 Loading and Running the PLC Program in the Fieldbus
Controller (ETHERNET)
Requirement:
• The simulation is deactivated (Online > Simulation).
• The PC is linked to the controller via ETHERNET. Refer to Section “Device
Description” > …> “ETHERNET – X1, X2 Network Connection”.
Proceed as follows:
1. In the menu bar click on Online and select Communication parameters
…. The “Communication Parameters” window opens.
2. To select a communication link click on [New …] in the “Communication
Parameters” window. A window opens in which you can define a
communication link.
Figure 69: Creating a Communication Link – Step 1

WAGO PFC200 2ETH RS XTR Specifications

General

Processor	ARM Cortex-A8
Clock Speed	600 MHz
RAM	256 MB
Ethernet Ports	2
Protection Class	IP20
Power Supply	24 V DC
Serial Ports	1 (RS-232/RS-485)
Operating Temperature	-40°C to +70°C
Programming Languages	IEC 61131-3
Certifications	UL
