Page #398 background image
398 Appendix WAGO I/O SYSTEM 750 XTR
750-8202/040-000 PFC200 2ETH RS XTR
Manual
Version 1.2.0, valid from FW Version 03.01.07(13)
Table 289: Description of Configuration Scripts for “Ports and Services” – “SSH/TFTP”
Parameters
Status
Call-Up
Output/Input
Valid
SSH
SSH Server
SSH
read get_ssh_config state
Read the status of the SSH port.
Possible return values:
- enabled
- disabled
Right
away
read
get_ssh_config root-
access-state
Indicates whether logon as root is
permitted.
Possible return values:
- enabled
- disabled
read
get_ssh_config
password-request-state
Indicates whether authentication
by password (instead of PKI key
files) is permitted.
Possible return values:
- enabled
- disabled
read
get_ssh_config port-
number
Specifies the SSH port
write
config_ssh
state=<Value>
Activate/Deactivate SSH service.
Possible entries for <Value>:
- enabled
- disabled
write
config_ssh port-
number=<Value>
Set the SSH port
write
config_ssh root-access-
state-value=<Value>
Permit/Prohibit logon as root.
Possible entries for <Value>:
- enabled
- disabled
write
config_ssh password-
request-state-
value=<Value>
Permit/Prohibit authentication by
password.
Possible entries for <Value>:
- enabled
- disabled
TFTP
TFTP Server
TFTP
read get_tftp_config state
Read the status of the TFTP port.
Possible return values:
- enabled
- disabled
Right
away
read
get_tftp_config
download-dir
Read the TFTP main directory.
write
config_tftp
state=<Value>
Activate/Deactivate TFTP port.
Possible entries for <Value>:
- enabled
- disabled
write
config_tftp download-
dir=<Value>
Set the TFTP main directory.
<
