WAGO PFC200 2ETH RS XTR User Manual

WAGO I/O SYSTEM 750 XTR Appendix 389
750-8202/040-000 PFC200 2ETH RS XTR
Manual
Version 1.2.0, valid from FW Version 03.01.07(13)
Table 281: Description of the Configuration Scripts for “Networking - TCP/IP”
Parameters
Status
Call
Output/Input
Effecti
ve
Default Gateway 1
Default
Gateway
read
get_default_gateway_
config number=1 state
Current status of the default
gateway 1.
Possible return values:
- enabled
- disabled
Immedia
tely
write
config_default_gateway
number=1
state=<stateval>
Possible entries for <Value>:
- enabled
- disabled
Default
Gateway
read
get_default_gateway_
config number=1 value
Current IP address of the default
gateway 1
Immedia
tely
write
config_default_gateway
number=1 value=<gw>
Enter the IP address of the
default gateway 1 here.
<gw> is an IP address with the
format “Number. Number.
Number. Number.”
Default
Gateway
read
get_default_gateway_
config number=1 metric
Current metric (cost factor) of the
default gateway 1
The default value is “20.”
Immedia
tely
write
config_default_gateway
number=1 metric=<n>
Enter the metric of the default
gateway 1 here.
<n> is a number between “0” and
“4.294.967.295.”
Default Gateway 2
See “Default Gateway 1.” When calling the gateway number, replace 1 with 2.
DNS Server 1
DNS Server 1
read get_dns_server 1
DNS server address with the
consecutive number 1
Immedia
tely
write/
change
edit_dns_server
dns-server-nr=1
change=change
dns-server-
name=<Value>
Set the address of the DNS
server with 1 as the consecutive
number.
<Value> is an IP address with the
format
“Number.Number.Number.Numbe
r.”
write/
delete
edit_dns_server
dns-server-nr=1
delete=delete
Delete the DNS server with the
consecutive number 1.
DNS Server 2 … n
See “DNS Server 1.” When calling, adjust the server number (2 … n).
Add DNS Server
Add DNS server write
edit_dns_server
add=add dns-server-
name=<Value>
Add additional DNS addresses
here.
<Value> is an IP address with the
format
“Number.Number.Number.Numbe
r.”
Immedia
tely

WAGO PFC200 2ETH RS XTR Specifications

General

Processor	ARM Cortex-A8
Clock Speed	600 MHz
RAM	256 MB
Ethernet Ports	2
Protection Class	IP20
Power Supply	24 V DC
Serial Ports	1 (RS-232/RS-485)
Operating Temperature	-40°C to +70°C
Programming Languages	IEC 61131-3
Certifications	UL
