Waters 2707 - Page 30

1-20 Understanding Operating Principles
3. The needle moves from the wash station to the sample vial. The injection
valve switches to the Load position.
Wash station
Buffer tubing
Syringe
Needle
Sample loop
LOAD
Column
Pump
Sample
