Technical Data
19088 - oat RD varh Reaktive energy L2
19090 - oat RD varh Reaktive energy L3
19092 - oat RD varh Reaktive energy L1..L3
19094 - oat RD varh Reaktive energy, inductive, L1
19096 - oat RD varh Reaktive energy, inductive, L2
19098 - oat RD varh Reaktive energy, inductive, L3
19100 - oat RD varh Reaktive energy, L1..L3, inductive
19102 - oat RD varh Reactive energy, capacitive, L1
19104 - oat RD varh Reactive energy, capacitive, L2
19106 - oat RD varh Reactive energy, capacitive, L3
19108 - oat RD varh Reactive energy, L1..L3, capacitive
19110 836 oat RD % Harmonic, THD, U L1-N
19112 838 oat RD % Harmonic, THD, U L2-N
19114 840 oat RD % Harmonic, THD, U L3-N
19116 908 oat RD % Harmonic, THD, I L1
19118 910 oat RD % Harmonic, THD, I L2
19120 912 oat RD % Harmonic, THD, I L3
Modbus
address
Address
above
display
Format RD/WR Unit Note Adjustment range Default
20022 - oat RD/WR A Current transformer I4, primary
0 to 1000000 5
20024 - oat RD/WR A Current transformer I4, secondary
1 to 5 5
The addresses contained in the description can be adjusted directly on the device in the range from 0 to 800.
The address range 800 to 999 is available for programming comparators on the device. The addresses above 1000 can only
be processed via modbus!
A complete overview of the parameters and measured values as well as explanations regarding the selected measured values
is led in the document “Modbus Address List” in the Internet on the product pages.
