Conguration
Recordings
2 recordings are precongured in the default factory setting of the
Energy Meter 610 and Energy Meter 610-PB. Recordings are ad-
justed and extended via the software “ecoExplorer go”.
• The smallest time base for records is 1 minute.
• A maximum of 4 recordings, each with 100 values are possible.
Recording 1:
The following measured values are recorded with the time base
of 15 minutes:
• Voltage effective L1
• Voltage effective L2
• Voltage effective L3
• Current effective L1
• Current effective L2
• Current effective L3
• Current effective Sum L1-L3
• Active Power L1
• Active Power L2
• Active Power L3
• Active Power Sum L1-L3
• Apparent Power L1
• Apparent Power L2
• Apparent Power L3
• Apparent Power Sum L1-L3
• cos phi(math.) L1
• cos phi(math.) L2
• cos phi(math.) L3
• cos phi(math.) Sum L1-L3
• Reactive power fundamental L1
• Reactive power fundamental L2
• Reactive power fundamental L3
• Reactive power fundamental Sum L1-L3
The mean value, minimum value and maximum value are also re-
corded for each measured value.
Recording 2:
The following measured values are recorded with the time base
of 1 hour:
• Active Energy Sum L1-L3
• Inductive Reactive Energy Sum L1-L3
“Drag indicator”
Max. value of the mean value over n minutes
The “drag indicator” describes a maximum mean value of a meas-
ured value over a dened period.
The period duration is set via a parameter, via the ecoExplorer go
software or via the digital input 1.
In the process, synchronisation is triggered via the internal clock
(which can be set via parameter 206 or to a full hour) or optionally
via digital input 1. If synchronisation via the digital input is selected,
the capture time must be set!
The thee highest values of 15 variables with time stamp are saved.
The maximum values of the variables can also be viewed in the
device display.
Variables:
• Current in the single phases L1...L3
• Effective power (consumption/export) in the single phases L1...
L3
• Effective power (consumption/export), total.
• Apparent power the single phases L1...L3
• Apparent power, total
Please note that even before averaging, the values
are divided between positive and negative ones!
During totalisation, rst the totals for the single phases
are calculated, then divided into positive and negative
values!
The maximum values are reset via the “Delete min./max. values”
function with the ecoExplorer go program, via Modbus or on the
display by setting the corresponding parameters (parameter 506:
set from 0 to 1).
Addr. Description Setting
range
Presetting
206 Period duration 300 to 3600 s 900
207 Capture time 1 to 20 s 10 s
208 Conguration
digital input 1
0 = internal synchronisa-
tion
1 = external synchronisa-
tion (NO)
2 = external synchronisa-
tion (NC)
0 to 2 0
506 Resetting 0, 1 0
