Technical Data
Technical Data
General
Net weight (with attached connectors) approx. 358g
Packaging weight (including acces-
sories)
approx. 790g
Battery Lithium battery CR2032, 3 V (ap-
proval i.a.w. UL 1642)
Service life of the backlight 40000 h (after this period of time the
background lighting efciency will
reduce by approx. 50 %)
Transport and storage
The following information applies for devices that are transported or stored in
their original packaging.
Free fall 1 m
Temperature K55 (-25 to +70 °C)
Relative humidity 0 to 90 % RH
Ambient conditions during operation
The Energy Meter 610/610-PB is intended for use in weather-protected, xed
locations.
Protection class II according to IEC 60563 (VDE 0106, part 1).
Rated temperature range K55 (-10 to +55 °C)
Relative humidity 0 to 75 % RH
Operational altitude 0 to 2000 m above sea level
Degree of pollution 2
Installation position vertical
Ventilation Forced ventilation is not required.
Foreign body and water protection
- Front
- Back
- Front with seal
IP40 according to EN 60529
IP20 according to EN 60529
IP54 according to EN 60529
Power supply voltage
Option 230V:
- Nominal range
- Power consumption
90 to 277 V (50/60 Hz)
or DC 90 to 250 V; 300 V CAT III
Type 610: 3 W / 6 VA
Type 610-PB: max. 4 W / 7,5 VA
Option 24V:
- Nominal range
- Power consumption
24 to 90 V AC/DC; 150 V CAT III
Type 610: 3 W / 5 VA
Type 610-PB: max. 5 W / 6,5 VA
Operating range +-10 % of nominal range
Internal fuse, not replaceable Type T1A / 250V/277V
according IEC 60127
Recommended overcurrent protec-
tion device for line protection (certi-
ed under UL)
Option 230 V: 6 to 16 A (Char. B)
Option 24 V: 1 to 6 A (Char. B)
Recommendation for a maximum number of devices on a circuit
breaker:
- Option 230 V: Circuit breaker B6A: max. 4 devices
Circuit breaker B16A: max. 11 devices
- Option 24 V: Circuit breaker B6A: max. 3 devices
Circuit breaker B16A: max. 9 devices
Connection capacity of the terminals (power supply)
Connectable conductor. Only one conductor may be connected per contact
point!
Single-wire, multi-wire, nely
stranded conductor
0.2 to 2.5.mm
2
, AWG 26 to 12
Pin terminals, ferrules 0.2 to 2.5.mm
2
Tightening torque 0.4 to 0.5.Nm
Stripping length 7 mm
