5.4.2.14 Parameter Setting of SANYO Q Servo Driver
Set electronic gear ratio for position command pulse.
E.G., incremental encoder 2000, the motor needs 2000
×4=8000 pulses per circle. When pulse equivalent of
Weihong CNC system is 0.001mm/p, it needs 1000
pulses to move 1mm along line, in other words, if the
screw pitch is 5, to move 5mm along line needs 5000
pulses, so F=8000/5000=8/5.
This setting is the same as that of electronic gear ratio 1
and activated during electronic gear switching.
Set position command pulse as ―pulse + direction‖.
Make the function of servo alarm effective.
Setting of the system parameters
Standard incremental encoder. The parameter depends
on the specific situation, what we list is only the
representative one.
Incremental
encoder
resolution
500－65535, set the encoder resolution manually.
Select position control mode.
