5.4.2.18 Parameter Setting of TECO TSDA Servo Driver
Para.
No.
Function
Value
Description
Pn010-1
Set control mode
1
Value
Control mode
CN1 Pin12 open
circuit
CN1 Pin12 closed
circuit
0
Speed control
Speed control
1
Position control
Position control
2
Torque control
Torque control
3
Speed control
Speed control
4
Position control
Position control
5
Torque control
Torque control
Pn010-2
Set the pulse
input format under
position control
mode
0
Value
The format of pulse input
0
Pulse + direction
1
Dipulse
2
A/B phase difference
Pn010-3
Set rotation
direction of motor
1
Value
Function
0
Motor rotates CCW with input of positive
order.
1
Motor rotates CW with input of positive
order.
Pn021
Electronic gear
ratio numerator
5
The input pulse amount will be multiplied by this
number before output. Ratio range of parameter 21
to 22:
1/127＜parameter 21/ parameter 22＜127
Pn022
Electronic gear
ratio denominator
1
Pn011-4
Set the function of
Pin20 of CN1
1
Value
Function
0
Output of ―0‖ speed signal
1
Output of brake signal
Pn013-1
Set the max.
pulse frequency
received by the
driver under
position control
mode
7
It can correct the phenomenon of unauthorized
over-travel. Received frequency is divided into 8
segments from 500Kpps to 200Kpps. ―0‖ indicates
500Kpps while ―7‖ 200Kpps.
CAUTION
For the parameter setting of driver of various brands, refer to the specific driver manual.
