3. To move X2-axis to the target position, click X2+ / X2- in Manual mode.
4. To clear X2-axis, click .
Note: During cutting, the distance between double tools keeps the value at clearing.
3.2.2 Set Y-axis Workpiece Origin
To set Y-axis workpiece origin, do the following:
1. To move Y-axis to the target position, click Y+ / Y- in Manual mode.
2. To clear Y-axis, click .
3.2.3 Set Z-axis Workpiece Origin
To set Z-axis workpiece origin, do the following:
1. To move Z1-axis to the target position, click Z1+ / Z1- in Manual mode.
2. To clear Z1-axis, click .
3. To move Z2-axis to the target position, click Z2+ / Z2- in Manual mode.
4. To clear Z2-axis, click .
You can also set Z-axis workpiece origin by measuring height. See Measure Height
for details.
