1 Overview
Phoenix Double-tool CNC System (hereinafter referred to as Double-tool CNC
System) consists of hardware and software:
Hardware
• NC65C industrial personal computer
• Lambda 5M terminal board
• DB9M/F cables
Software
Phoenix double-tool software: see Main Software Interface for the introduction of its
main software interface.
1.1 NC65C Industrial Personal Computer
NC65C industrial personal computer, also called NC65C Controller (hereinafter
referred to as NC65C). Compared with NC65A and NC65B, NC65C has faster clock
frequency and memory rate and better antivirus capacity. Additionally, its
performance has improved about 40%, which leads to smoother operation.
NC65C is compatible with the board, FPGA firmware and the unit of NC65B. It can
be applied to various industries when mated with Lambda terminal board.
1.1.1 Layout
The interface layout of NC65C is as follows:
