APPENDIX B: FAULT CODES
Contact a Weiler dealer for engine fault codes.
ELECTRONIC DISPLAY ERROR FAULT CODES
Error descriptions are shown on the View Errors Screen.
ERROR DESCRIPTION ERROR STATE
DISPLAY VOLTAGE HIGH
DISPLAY VOLTAGE GREATER THAN 29 VOLTS FOR 2
SEC.
DISPLAY VOLTAGE LOW DISPLAY VOLTAGE LOWER THAN 6 VOLTS FOR 2 SEC.
CONTROLLER VOLTAGE HIGH
CONTROLLER VOLTAGE GREATER THAN 29 VOLTS FOR
2 SEC.
CONTROLLER VOLTAGE LOW
CONTROLLER VOLTAGE LOWER THAN 6 VOLTS FOR 2
SEC.
PROPEL FORWARD OUT OF
RANGE
OUTPUT IS MORE THAN 15 mA LESS OR MORE THAN
THE COMMANDED OUTPUT AND THE COMMANDED
VALUE IS GREATER THAN .3 A FOR 2 SEC
PROPEL REVERSE OUT OF RANGE
OUTPUT IS MORE THAN 15 mA LESS OR MORE THAN
THE COMMANDED OUTPUT AND THE COMMANDED
VALUE IS GREATER THAN .3 A FOR 2 SEC
ELEVATOR TRANSDUCER
VOLTAGE HIGH
VOLTAGE IS ABOVE 4.9 Vdc
ELEVATOR TRANSDUCER
VOLTAGE LOW
VOLTAGE IS BELOW .1 Vdc
TWO SPEED COIL OUT OF RANGE
OUTPUT IS MORE THAN 15 mA LESS OR MORE THAN
THE EXPECTED OUTPUT AND THE OUTPUT IS ON FOR 2
SEC
PROPEL JOYSTICK FAULT JOYSTICK COMMUNICATION FAULT
PROPEL KNOB CALIBRATION HIGH
VOLTAGE IS GREATER THAN LEFT TRACK HI CAL FOR 2
SEC
PROPEL KNOB CALIBRATION LOW
VOLTAGE IS LESS THAN LEFT TRACK LO CAL FOR 2
SEC
STORAGE TRANSDUCER
VOLTAGE HIGH
VOLTAGE IS ABOVE 4.9 Vdc
STORAGE TRANSDUCER
VOLTAGE LOW
VOLTAGE IS BELOW .1 Vdc
CONVEYOR TRANSDUCER
VOLTAGE HIGH
VOLTAGE IS ABOVE 4.9 Vdc
CONVEYOR TRANSDUCER
VOLTAGE LOW
VOLTAGE IS BELOW .1 Vdc
FUEL VOLTAGE HIGH VOLTAGE IS ABOVE 4.9 Vdc
FUEL VOLTAGE LOW VOLTAGE IS BELOW .1 Vdc
GROUND SPEED SENSOR LOW/NO
SPEED ERROR
PUMP IS OUTPUTTING GREATER THAN 30 mA WITH NO
SPEED FOR 2 SECONDS
