WEILER E1650 REMIXING TRANSFER VEHICLE
2-2
Machine Controls
2
Machine Terminology
MACHINE TERMINOLOGY
(1) Battery Box
(2) Discharge Conveyor
(3) Conveyor Control Station
(4) Dump Hopper
(5) Dump Hopper Lights and Headlights
(6) Dump Hopper Control Station
(7) Elevator
(8) Engine and Pump Compartment
(9) Main Operator Control Station
(10) Storage Hopper and Conveyor
(11) Work Lights
Front
Rear
Right
Left
