136
eikon e1s
Service and repair guide
3.
To remove the stirrer from the motor spindle, the motor must be prevented
from moving. This is most easily achieved by holding one of the white cogs
located below the motor.
The stirrer can then be removed by turning clockwise.
Remove the remains of the old gasket before fitting the new impinger plate
(comes with gasket).
Fitting the stirrer
• Follow the steps in the reverse order to fit the stirrer.
• When refitting the partition plate, fasten the screws on opposite corners/sides in turns and do NOT proceed
stringently clockwise or counterclockwise.
• Tighten the partition plate screws to 2.1 Nm of torque.
