eikon e1s
Service and repair guide
Temperature timer setting
1. Select the ‘thermometer / timer’ symbol from the settings menu.
2. Select the ‘timer enabled’ checkbox (green checkmark).
3. Select a weekday using the up/down arrows at the bottom of the
screen.
4. Select an empty ‘time’ box (maximum of five per day) or clear an
existing ‘time’ box using the ‘wipe’ symbol next to it.
5. Enter the start time on the keypad.
Press the green checkmark to continue.
6. Select an empty ‘temperature’ box opposite the respective ‘time’
box or clear the required ‘temperature’ box using the ‘wipe’
symbol next to it.
7. Enter the cavity temperature required on the keypad.
Alternatively:
• Select zero to turn the heat OFF.
• Select the red circle symbol to switch OFF the appliance.
Press the green checkmark to continue.
